Hydraulic Tipper Semi Trailer

3 Axle Tipper Trailer for Sale:

Sinoturk Tanzania different types of 3 axle hydraulic tipper trailer for sale in Tanzania to meet your different needs, like hydraulic tipper , tipper semi trailer , hydraulic tipper trailer , tipper semi trailer for sale , 3 axle tipper trailer for sale , 3 axle tipper trailer , new tipper trailers for sale.

In civil engineering, often works in conjunction with excavators, loaders, belt conveyors and other construction machinery. The new tipper trailers for sale in Tanzania carriage adopts rear-dump and side dump self-unloading methods, which improves the efficiency of the bulk cargo transport by the loader.

Hydraulic Tipper Semi Trailer for Sale | New 3 Axle Tipper Trailer for Sale in Tanzania Dar Es Salaam

Hydraulic Tipper Semi Trailer for Sale | New 3 Axle Tipper Trailer for Sale in Tanzania Dar Es Salaam

Hydraulic Tipper Semi Trailer for Sale | New 3 Axle Tipper Trailer for Sale in Tanzania Dar Es Salaam

Hydraulic Tipper Trailer Advantage:

1. Hydraulic cylinder: The heavy-duty cylinder with a wider diameter, stronger lifting capacity and higher height, which makes the lifting more stable and does not easy to roll over.

2. Double-plate main beam for tipper semi trailer, which has a stronger carrying capacity, it is not easy to damage.

3. with 4 units vice beam and cross balance beam. The lattice structure of the side door makes the side door more solid.

4. The leaf spring is widened and thickened, the shock absorption effect is good.

5. Strengthened Ribs, unique structure design to maximize the payload.

Specification of tipper semi trailer:

Dimension: 11280mmx2495mm x3970mm ( inside dimension )

Main beam: Height: 480mm-500mm, Upper plate: 16mm-25mm, Middle plate: 12mm-20mm, Lower plate: 18mm-25mm, Material: T700 steel.

Tare Weight (semi trailer): About 15600kg

Total volume(m³): 30-40m³ or less than 100tons

Side wall thickness: 4 - 6mm

End plate: 8mm

Lifting System: Full set of HYVA lifting cylinder

Axle: 13T/16T, FUWA / BPW / TITAN Brand

Rim: 8.0-20 or 9.00-20

Tire: 8.25R20/10.00R20/11.00R20/12R22.5

Suspension: Mechanical suspension

Spring leaf: 90(W)mmx13(Thickness)mmx10 layers

Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)

Landing gear: JOST brand

Through these videos, you can learn about different types of tipper trailers, as well as the process, testing, packaging and customer feedback, etc.

Welcome to leave your inquiry! We will provide more details, price, catalog, drawing, videos for you!
